Product Type Features

Connector Shape : Rectangular
Connector System : Wire-to-Wire
Connector & Housing Type : Housing for Male Terminals
Sealable : No
Connector & Contact Terminates To : Wire & Cable
Primary Locking Feature : Integrated in Housing
Mixed & Hybrid Connector : Yes
Configuration Features

Number of Positions : 102
Number of Rows : 12
Blank Cavity Position : 0
Electrical Characteristics

Operating Voltage (VAC): 250
Operating Voltage (VDC): 250
Nominal Voltage Architecture (V): 250
Body Features

Cable Exit Angle : 180°
Primary Product Color : Black
Connector & Keying Code : A
Contact Features

Contact Type : Pin
Contact Size : Size 12, Size 16, Size 4, Size 8
Mating Pin Diameter (mm): 1.59, 2.39, 3.61, 5.72
Mating Pin Diameter (in): .063, .094, .142, .225
Contact Current Rating (Max) (A): 13, 25, 60, 100
Mechanical Attachment

Mating Alignment : With
Mating Alignment Type : Keyed
Strain Relief : With
Connector Mounting Type : Cable Mount (Free-Hanging)
Terminal Position Assurance : No
Housing Features

Housing Material : PA GF
Centerline (Pitch) (mm): 4.45, 6.71, 22.5
Centerline (Pitch) (in): .175, .264, .886
Dimensions

Compatible Insulation Diameter Range (mm): 1.35 – 3.05, 2.46 – 4.01, 3.43 – 5.59, 6.63 – 7.42
Compatible Insulation Diameter Range (in): .053 – .12, .097 – .158, .135 – .22, .261 – .292
Row-to-Row Spacing (mm): 3.81, 4.83, 6.6, 7.62, 8.61, 8.63
Row-to-Row Spacing (in): .15, .19, .26, .3, .339, .34
Product Length : 54.38 mm [ 2.141 in ]
Product Width : 125.76 mm [ 4.951 in ]
Connector Height : 62.64 mm [ 2.466 in ]
Usage Conditions

Operating Temperature (Max) : 125 °C [ 257 °F ]
Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
Operation/Application

Circuit Application : Power
Industry Standards

Compatible With Agency/Standards Products : SAE J2030
Degree of Protection : IP68, IP6K9K
